Top class plasma cutter Plasma-Jet DSL 40330

• PREMIUM units of plasma cutting with wide range of additional accessory equipment, 6-axis cutting is also possible
• Selection of optimized plasma source Hypertherm
• Numerical control Hypertherm® MicroEDGE® Pro with software
• Bilateral drive
• All axes have high-quality guides
• All coordinates have dynamic AC servo drives with a zero-backlash planetary drive that requires no maintenance
• Wear-resistant rack-and-gear drives require low maintenance and are designed for continuous operation
• Optimum cutting speed even when cutting small contours and narrow circles
• Automatic height regulation of a cutting head plasma arc
• Rugged steel design of a free-standing plasma cutting table with high load capacity
• Controlled cutting current
• Stand-alone layout excludes mechanical and thermal impact on a driving mechanism
• Instant replacement of a cutting head by a fast latching mechanism
• High rate profitability due to the lowest time consumption for tooling
• In numerical control there is a settings database for optimum cutting
• It is possible to package the unit with a 5-axis cutting head, pipe cutter and other optional accessory components
