Vertical single inlet pump with a submersible electric motor. It is used in water supply, pumping of rain water, various sewage disposals, sea water, water cooling systems.
Vertical centrifugal pump with a radial-split casing, foot-mounted on the supporting surface. The double inlet impeller allows for axial load compensation. This pump is used as a main dewatering pump in floating docks.
Horizontal centrifugal pump with a radial split, foot-mounted. The pump has a single volute casing. The pump is used for water cooling, drinking and sea water pumping, hot water under pressure pumping.
Horizontal single-stage pump with an axial-split casing and a double inlet impeller, it is installed on base plate supports. Closed double inlet impellers eliminate axial load. These pumps are used in dewatering systems, mineral resource industry, water supply and fire water systems, cooling towers, municipal services, sugar plants, pulp and paper industry, power industry.
Pumps with a horizontal split, certified for fire-fighting systems. Ruhrpumpen fire pumps are certified by Underwriter Laboratories Inc and approved by Factory Mutual. The pumps are used in fire-fighting systems.
Vertical multi-stage centrifugal pump with a vaned diffuser. Closed impellers with special-shape blades. Various filter elements can be used depending on operating conditions. These pumps are used for artesian wells and irrigations, pumping of slurry and condensates, fire-fighting. They are also used by municipal services in general industrial use.
The CRP line features 35 sizes to precisely meet service conditions within a wide range of hydraulic parameters, including the range of low output flow and high head. The line was also designed to accommodate many different optional features such as wear rings on the pressure casing and impeller or cooling coils for seal chambers bearing housings.
CRP pump is designed to meet DIN EN ISO 2858 / 5199 specifications and directive 94/9/EG (ATEX 100). All CRP pumps have the same design solutions for a flow part and other parts of the pump. This ensures efficiencies across a wide spectrum of operating conditions, unmatched application flexibility and superior interchangeability. These centrifugal pumps are designed to operate dependably for long periods of time, even in the toughest industrial applications.
This centrifugal pump with a magnetic coupling is designed to meet DIN EN 22858 and DIN EN ISO 15783 standards. Pumps of CRP-M product line, accomplished by magnetic drives with permanent magnets as per DIN EN 22858 and DIN EN ISO 15783 standards, have innovatory design solutions of the journal bearings, internal flushing system with optimum allocation of flow and pressure, highly-effective magnetic drive and axial load discharge system. As a 100% leakage free pump the CRP-M avoids high maintenance costs and usage of mechanical seals. It is also the best option for taking care of the environment and meets the requirements of the TA-Luft specification (German Technical Instruction on Air Quality Control)
Delayed Coking is a process which produces gas, gas oils and coke. The furnace provides the heat which starts the vaporisa-tion and cracking at approximately 485° C (905° F). As the feed enters the drum at the bottom the cracking and polymerisation continues until solid coke is formed and the gases go overhead to the fractionation tower. When the drum is nearly full the feed is switched over to the second drum.
Two- and four-stage horizontal centrifugal pumps are made of grey cast iron. Double volute. Horizontally split casing, side-side nozzle arrangement. It is used in high pressure systems (boiler feed systems, facilities of petrochemical and chemical industries, industrial systems of general purpose).
This heavy-duty process pump is designed to meet API 610 standard latest edition (BB3 type). Construction materials fully meet the requirements of API 610 standard. It is equipped with replaceable split ring seals of the casing and impeller. It can be fitted with a cooling fan and bearing water-cooling system.
The pump ensures efficient operation under unfavorable conditions. No need for an auxiliary vacuum pump to maintain the priming. It is equipped with a pollution prevention system to reduce expenses on cleaning from the pumped product. It can be made of different construction materials depending on application conditions.
Ruhrpumpen LVZ – Single-stage or multi-stage radially split centrifugal pump. There is a diffuser casing. These pumps are used as wash-down pumps in floating docks and fire protection service in offshore applications.
This heavy duty process pump is designed under the latest edition of API 610 (BB2 type). There are oil-ring bearings. A cooling fan and bearing water-cooling system is available. Coke crusher design is available for the flow part. It is used at oil refineries, oil fields, petrochemical and chemical plants.
This heavy duty process pump is designed under the latest edition of API 610 standard (BB3 type). Bearings are lubricated by a spray ring. It is used at oil fields and terminals, oil and product pipelines, in case of fluid injections into formations.
Vertical circulator pumps, centrifugal axial (diagonal-flow) and centrifugal, single-stage and multi-stage. Pumps of VCT product line are semi-submersible. These are vertically suspended pumps, single case, multi-stage with diagonal or semi-diagonal impellers. If required, they can be designed in compliance with API 610 standard latest edition (VS1 type). Also they can be made with a double case, then they become VMT model pumps (VS6 type as per API 610).
Multi-stage vertical centrifugal pump, diffuser type. It is designed to meet API 610 standard (pump type VS3). All applications that require large quantities of water with low head, including drainage, flood control, irrigation, waste treatment plants, condenser cooling, construction dewatering and raw water intakes.
VSP is a sump pump with a semi-open impeller. It is designed to handle water with minimum amount of solids. VSP Non-Clog is a sump pump with an enclosed impeller, it is designed to handle water with solids up to 100 mm in diameter. Standard construction material for both models is cast iron, but these pumps can be made of other materials on request. Ruhrpumpen offers 28 different standard sizes of VSP sump pumps and 18 standard sizes of VSP Non-Clog pumps. Engineering experience gained by Ruhrpumpen makes it possible to manufacture pumps of this model in special design, big standard sizes and using any materials as required by the customer.
VTG is a vertical multi-stage centrifugal pump, which also can be used as a turbine generator. High efficiency and improved hydraulic characteristics prevent flow choking. It is designed under the latest edition of API 610 standard.
ZM process pump with a horizontal-split casing is designed under the latest edition of API 610 standard (BB1 type) for heavy-duty. It can be foot or near-centerline mounted. It is designed with a double-volute casing and a diffuser casing. Closed double-suction impeller compensates axial load.
Transportable (modular) boiler plants TBP (MBP) are ready-to-operate mobile boiler units designed for heating, ventilation and hot water supply for industrial, residential and community facilities. Boiler plants are fired with natural gas, liquefied gas, diesel fuel, fuel oil, oil and solid fuel (coal, wood, pellets, etc.). All process equipment is housed within a plant-manufactured modular unit. A boiler plant casing should be all-metal, heat-insulated, fire-proof. Boiler plants can also be frame-mounted for indoor installation.
BXC Series motorized transfer cart is powered by a storage battery. This type of rail transfer cart rides the track within or between workshops in a factory. It has simple design and beautiful appearance. The cart is easy-to-use and maintain, it has large carrying capacity and low noise level, it is environmentally friendly and has a good safety performance. This cart is widely used for transportation within or between workshops together with a crane to move heavy load or equipment. In a working environment it can be used without power source or long distance transportation. BXC Series electric transfer carts are designed for 24V, 36V and 48V DC. A storage battery feeds power to a traction electric motor and it puts the cart in motion. Compared with an AC motor, a DC motor is uneasy to burn and has larger start torque. The cart can run on curving or ring rails and has no limits in running distances as well as no special requirements for rails. The cart design is convenient for inspection and maintenance, assembly and disassembly. Besides, it has large load capacity, low deformation ratio of a load platform, long service life, smooth start and stop.
THE SYSTEM IS DESIGNED AND DELIVERED INDIVIDUALLY AND ACCORDING TO CUSTOMER TECHNICAL REQUIREMENTS.
Conveyor scales WBS for flow metering of different bulk solid materials on a belt conveyor. Conveyor scales are designed for flow metering of different bulk solid materials on a belt conveyor. Rigid design for direct loading without levers, joints and supports. Easy to install and adjust. Fast delivery time and availability of spare parts. Various designs depending on accuracy requirements and conveyor profile. Special high-accuracy design for fiscal metering. Data transmission via wireless communication of GSM standard. Range of use: fiscal and process metering of materials on conveyors (measurement of current output, material consumption).
The scales come standard with a roller conveyor unit up to 20.000 mm, a set of rollers with a direct motor drive, a set of weight measuring equipment, an adjustable-speed drive, an automatic control system of load mechanisms.
SCALES ARE DESIGNED ON AN INDIVIDUAL BASIS ACCORDING TO TECHNICAL REQUIREMENTS.
Automatically-controlled terminals for transport registration without an operator makes it possible to save time and reduce expenses by logistics automatisation. Automatic transport identification by embedded video observation or radio-frequency identification systems helps to increase the terminal capacity. There is data communication to enterprise management systems and accounting software systems.
DESIGNED AND DELIVERED INDIVIDUALLY AND ACCORDING TO TECHNICAL REQUIREMENTS.
